Sewage, waste water, industrial effluent, paper and pulp mills waste or any other waste flowing with high volume of debris. Most suitable for external nala or external flowing water bodies.
Width of Screen :
450mm to 4000mm for Multirake configuration.
Length of Screen :
Up to 16000mm
Angle of Inclination :
70 to 75 degrees with horizontal
Preferred MOC :
304 Stainless Steel or Better
Opening of Screen :
20mm to 60mm
Scrappers :
Thru-Bar Screen
Drive :
Suitable Electric Motor
Operating Speed :
Minimum speed 0.5 RPM depending on flow and percentage of debris / screenings, speed can be changed..
Controls Types :
Manual, semi-automatic, automatic and fully automatic controlled by PLC with Torque limit switch.
Benefits
Very Compact occupies very less space.
Suitable to a Wide Range of Debris Variations.
Available with/without Conveyor.
Easy to Erect and Operate.
Effective Capture Thru-Bar Scrappers.
Fully automatic PLC controlled system (Optional).
Can be transported to any location Mobile unit (Optional).
